User-defined functions (UDFs) are a very useful feature supported in SQL++. Couchbase 7.6 introduces improvements that allow for more debuggability and visibility into UDF execution.
This blog will explore two new features in Couchbase 7.6 in the world of UDFs.
-
- Profiling for SQL++ statements executed in JavaScript UDFs
- EXPLAIN FUNCTION to access query plans of SQL++ statements within UDFs
The examples in this post require the travel-sample dataset to be installed.
Profiling SQL++ Executed in JavaScript UDFs
Query profiling is a debuggability feature that SQL++ offers.
When profiling is enabled for a statement’s execution, the result of the request includes a detailed execution tree with timing and metrics of each step of the statement’s execution. In addition to the profiling information being returned in the results of the statement, it can also be accessed for the request in the system:active_requests and system:completed_requests system keyspaces.
Here is a post that delves deeper into request profiling.
In Couchbase 7.0, profiling was included for subqueries, including profiling subqueries from Inline UDFs.
However, with new features in Couchbase 7.6, profiling was extended to SQL++ statements within JavaScript UDFs.
In earlier versions, to profile statements within a JavaScript UDF, the user would be required to open up the function’s definition, individually run each statement within the UDF and collect their profiles. This additional step will no longer be needed in 7.6.0!
Now, when profiling is enabled, if the statement contains JavaScript UDF execution, profiles for all SQL++ statements executed in the UDF will also be collected. And this UDF related profiling information will be available in the request output, system:active_requests and system:completed_requests system keyspaces as well.
Example 1:
Create a JavaScript UDF js1 in a global library lib1 via the REST endpoint or via the UI.
|
1 2 3 4 5 6 7 8 9 10 11 12 |
function js1() { var query = SELECT * FROM default:`travel-sample`.inventory.airline LIMIT 1; var res = []; for (const row of query) { res.push(row); } query.close() return res; } |
Create the corresponding SQL++ function:
|
1 |
CREATE FUNCTION js1() LANGUAGE JAVASCRIPT AS "js1" AT "lib1"; |
Execute the UDF with profiling enabled:
|
1 |
EXECUTE FUNCTION js1(); |
In the profile section of the returned response, the executionTimings subsection contains a field ~udfStatements.
~udfStatements is an array of profiling information that contains an entry for every SQL++ statement within the JavaScript UDF.
Every entry within the ~udfStatements section contains:
-
- executionTimings – The execution tree for the statement. It has metrics and timings information of every step of the statement’s execution.
- statement – The statement string.
- function – The name of the function where the statement was executed. This is helpful to identify the UDF that executed the statement when there are nested UDF executions.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 |
{ "requestID": "2c5576b5-f01d-445f-a35b-2213c606f394", "signature": null, "results": [ [ { "airline": { "callsign": "MILE-AIR", "country": "United States", "iata": "Q5", "icao": "MLA", "id": 10, "name": "40-Mile Air", "type": "airline" } } ] ], "status": "success", "metrics": { "elapsedTime": "20.757583ms", "executionTime": "20.636792ms", "resultCount": 1, "resultSize": 310, "serviceLoad": 2 }, "profile": { "phaseTimes": { "authorize": "12.835µs", "fetch": "374.667µs", "instantiate": "27.75µs", "parse": "251.708µs", "plan": "9.125µs", "primaryScan": "813.249µs", "primaryScan.GSI": "813.249µs", "project": "5.541µs", "run": "27.925833ms", "stream": "26.375µs" }, "phaseCounts": { "fetch": 1, "primaryScan": 1, "primaryScan.GSI": 1 }, "phaseOperators": { "authorize": 2, "fetch": 1, "primaryScan": 1, "primaryScan.GSI": 1, "project": 1, "stream": 1 }, "cpuTime": "468.626µs", "requestTime": "2023-12-04T20:30:00.369+05:30", "servicingHost": "127.0.0.1:8091", "executionTimings": { "#operator": "Authorize", "#planPreparedTime": "2023-12-04T20:30:00.369+05:30", "#stats": { "#phaseSwitches": 4, "execTime": "1.918µs", "servTime": "1.125µs" }, "privileges": { "List": [] }, "~child": { "#operator": "Sequence", "#stats": { "#phaseSwitches": 2, "execTime": "2.208µs" }, "~children": [ { "#operator": "ExecuteFunction", "#stats": { "#itemsOut": 1, "#phaseSwitches": 4, "execTime": "22.375µs", "kernTime": "20.271708ms" }, "identity": { "name": "js1", "namespace": "default", "type": "global" } }, { "#operator": "Stream", "#stats": { "#itemsIn": 1, "#itemsOut": 1, "#phaseSwitches": 2, "execTime": "26.375µs" }, "serializable": true } ] }, "~udfStatements": [ { "executionTimings": { "#operator": "Authorize", "#stats": { "#phaseSwitches": 4, "execTime": "2.626µs", "servTime": "7.166µs" }, "privileges": { "List": [ { "Priv": 7, "Props": 0, "Target": "default:travel-sample.inventory.airline" } ] }, "~child": { "#operator": "Sequence", "#stats": { "#phaseSwitches": 2, "execTime": "4.375µs" }, "~children": [ { "#operator": "PrimaryScan3", "#stats": { "#itemsIn": 1, "#itemsOut": 1, "#phaseSwitches": 7, "execTime": "22.082µs", "kernTime": "1.584µs", "servTime": "791.167µs" }, "bucket": "travel-sample", "index": "def_inventory_airline_primary", "index_projection": { "primary_key": true }, "keyspace": "airline", "limit": "1", "namespace": "default", "optimizer_estimates": { "cardinality": 187, "cost": 45.28617059639748, "fr_cost": 12.1780009122802, "size": 12 }, "scope": "inventory", "using": "gsi" }, { "#operator": "Fetch", "#stats": { "#itemsIn": 1, "#itemsOut": 1, "#phaseSwitches": 10, "execTime": "18.376µs", "kernTime": "797.542µs", "servTime": "356.291µs" }, "bucket": "travel-sample", "keyspace": "airline", "namespace": "default", "optimizer_estimates": { "cardinality": 187, "cost": 192.01699202888378, "fr_cost": 24.89848658838975, "size": 204 }, "scope": "inventory" }, { "#operator": "InitialProject", "#stats": { "#itemsIn": 1, "#itemsOut": 1, "#phaseSwitches": 7, "execTime": "5.541µs", "kernTime": "1.1795ms" }, "discard_original": true, "optimizer_estimates": { "cardinality": 187, "cost": 194.6878862611588, "fr_cost": 24.912769445246838, "size": 204 }, "preserve_order": true, "result_terms": [ { "expr": "self", "star": true } ] }, { "#operator": "Limit", "#stats": { "#itemsIn": 1, "#itemsOut": 1, "#phaseSwitches": 4, "execTime": "6.25µs", "kernTime": "333ns" }, "expr": "1", "optimizer_estimates": { "cardinality": 1, "cost": 24.927052302103924, "fr_cost": 24.927052302103924, "size": 204 } }, { "#operator": "Receive", "#stats": { "#phaseSwitches": 3, "execTime": "10.324833ms", "kernTime": "792ns", "state": "running" } } ] } }, "statement": "SELECT * FROM default:`travel-sample`.inventory.airline LIMIT 1;", "function": "default:js1" } ], "~versions": [ "7.6.0-N1QL", "7.6.0-1847-enterprise" ] } } } |
Query Plans with EXPLAIN FUNCTION
SQL++ offers another wonderful capability to access the plan of a statement with the EXPLAIN statement. But the EXPLAIN statement does not extend to plans of statements within UDFs—neither Inline or JavaScript UDFs.
In earlier versions, to analyze the query plans for SQL++ within a UDF it would require the user to open the function’s definition, and individually run an EXPLAIN on all the statements within the UDF.
These extra steps are minimized in Couchbase 7.6 with the introduction of a new statement—EXPLAIN FUNCTION. This statement does exactly what EXPLAIN does, but for SQL++ statements within a UDF.
Let’s explore how to use the EXPLAIN FUNCTION statement!
Syntax
|
1 |
explain_function ::= 'EXPLAIN' 'FUNCTION' function |
Here, function refers to the name of the function.
For more detailed information on syntax, please check out the documentation.
Prerequisites
To run EXPLAIN FUNCTION on a UDF, the user must have sufficient RBAC permissions to execute the function.
The user must also have the necessary RBAC permissions to execute the SQL++ statements within the UDF function body.
Here are the roles supported in Couchbase.
Inline UDF
EXPLAIN FUNCTION on an inline UDF will return the query plans of all the subqueries within its definition.
Example 2 – EXPLAIN FUNCTION on an inline function
Create an inline UDF and run EXPLAIN FUNCTION on it:
|
1 2 3 |
CREATE FUNCTION inline1() { ( SELECT * FROM default:`travel-sample`.inventory.airport WHERE city = "Zachar Bay" ) }; |
|
1 |
EXPLAIN FUNCTION inline1(); |
The results of the above statement will contain:
-
- function – The name of the function EXPLAIN FUNCTION was run on.
- plans – An array of plan information that contains an entry for every subquery within the Inline UDF.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 |
{ "function": "default:inline1", "plans": [ { "cardinality": 1.1176470588235294, "cost": 25.117642854609013, "plan": { "#operator": "Sequence", "~children": [ { "#operator": "IndexScan3", "bucket": "travel-sample", "index": "def_inventory_airport_city", "index_id": "2605c88c115dd3a2", "index_projection": { "primary_key": true }, "keyspace": "airport", "namespace": "default", "optimizer_estimates": { "cardinality": 1.1176470588235294, "cost": 12.200561852726496, "fr_cost": 12.179450078755286, "size": 12 }, "scope": "inventory", "spans": [ { "exact": true, "range": [ { "high": "\\"Zachar Bay\\"", "inclusion": 3, "index_key": "`city`", "low": "\\"Zachar Bay\\"" } ] } ], "using": "gsi" }, { "#operator": "Fetch", "bucket": "travel-sample", "keyspace": "airport", "namespace": "default", "optimizer_estimates": { "cardinality": 1.1176470588235294, "cost": 25.082370508382763, "fr_cost": 24.96843677065826, "size": 249 }, "scope": "inventory" }, { "#operator": "Parallel", "~child": { "#operator": "Sequence", "~children": [ { "#operator": "Filter", "condition": "((`airport`.`city`) = \\"Zachar Bay\\")", "optimizer_estimates": { "cardinality": 1.1176470588235294, "cost": 25.100006681495888, "fr_cost": 24.98421650449632, "size": 249 } }, { "#operator": "InitialProject", "discard_original": true, "optimizer_estimates": { "cardinality": 1.1176470588235294, "cost": 25.117642854609013, "fr_cost": 24.99999623833438, "size": 249 }, "result_terms": [ { "expr": "self", "star": true } ] } ] } } ] }, "statement": "select self.* from `default`:`travel-sample`.`inventory`.`airport` where ((`airport`.`city`) = \\"Zachar Bay\\")" } ] } |
JavaScript UDF
SQL++ statements within JavaScript UDFs can be of two types and EXPLAIN FUNCTION works differently based on the way the SQL++ statement is called.
Here is the documentation reference to calling SQL++ in JavaScript functions.
Embedded SQL++
-
- Embedded SQL++ is “embedded” in the function body and its detection is handled by the JavaScript transpiler.
- EXPLAIN FUNCTION can return query plans for embedded SQL++ statements.
SQL++ executed by the N1QL() function call
-
- SQL++ can also be executed by passing a statement in the form of a string as an argument to the N1QL() function.
- When parsing the function for potential SQL++ statements to run the EXPLAIN on, it is difficult to get the dynamic string in the function argument. This can only be reliably resolved at runtime.
- With this reasoning, EXPLAIN FUNCTION does not return the query plans for SQL++ statements executed via N1QL() calls. But instead returns the line numbers where the N1QL() function calls have been made. This line number is calculated from the beginning of the function definition.
- The user can then map the line numbers in the actual function definition and investigate further.
Example 3 – EXPLAIN FUNCTION on an external JavaScript function
Create a JavaScript UDF js2 in a global library lib1 via the REST endpoint or via the UI:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
function js2() { // SQL++ executed by a N1QL() function call var query1 = N1QL("UPDATE default:`travel-sample` SET test = 1 LIMIT 1"); // Embedded SQL++ var query2 = SELECT * FROM default:`travel-sample` LIMIT 1; var res = []; for (const row of query2) { res.push(row); } query2.close() return res; } |
Create the corresponding SQL++ function:
|
1 |
CREATE FUNCTION js2() LANGUAGE JAVASCRIPT AS "js2" AT "lib1"; |
Run EXPLAIN FUNCTION on the SQL++ function:
|
1 |
EXPLAIN FUNCTION js2; |
The results of the above statement will contain:
-
- function – The name of the function EXPLAIN FUNCTION was run on.
- line_numbers – An array of line numbers calculated from the beginning of the JavaScript function definition where there are N1QL() function calls.
- plans – An array of plan information that contains an entry for every embedded SQL++ statement within the JavaScript UDF.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 |
{ "function": "default:js2", "line_numbers": [ 4 ], "plans": [ { "cardinality": 1, "cost": 25.51560885530435, "plan": { "#operator": "Authorize", "privileges": { "List": [ { "Target": "default:travel-sample", "Priv": 7, "Props": 0 } ] }, "~child": { "#operator": "Sequence", "~children": [ { "#operator": "Sequence", "~children": [ { "#operator": "Sequence", "~children": [ { "#operator": "PrimaryScan3", "index": "def_primary", "index_projection": { "primary_key": true }, "keyspace": "travel-sample", "limit": "1", "namespace": "default", "optimizer_estimates": { "cardinality": 31591, "cost": 5402.279801258844, "fr_cost": 12.170627071041082, "size": 11 }, "using": "gsi" }, { "#operator": "Fetch", "keyspace": "travel-sample", "namespace": "default", "optimizer_estimates": { "cardinality": 31591, "cost": 46269.39474997121, "fr_cost": 25.46387878667884, "size": 669 } }, { "#operator": "Parallel", "~child": { "#operator": "Sequence", "~children": [ { "#operator": "InitialProject", "discard_original": true, "optimizer_estimates": { "cardinality": 31591, "cost": 47086.49704894546, "fr_cost": 25.489743820991595, "size": 669 }, "preserve_order": true, "result_terms": [ { "expr": "self", "star": true } ] } ] } } ] }, { "#operator": "Limit", "expr": "1", "optimizer_estimates": { "cardinality": 1, "cost": 25.51560885530435, "fr_cost": 25.51560885530435, "size": 669 } } ] }, { "#operator": "Stream", "optimizer_estimates": { "cardinality": 1, "cost": 25.51560885530435, "fr_cost": 25.51560885530435, "size": 669 }, "serializable": true } ] } }, "statement": "SELECT * FROM default:`travel-sample` LIMIT 1 ;" } ] } |
Constraints
If the N1QL() function has been aliased in a JavaScript function definition, EXPLAIN FUNCTION will not be able to return the line numbers where this aliased function was called. For example:
|
1 2 3 4 |
function js3() { var alias = N1QL; var q = alias("SELECT 1"); } |
If the UDF contains nested UDF executions, EXPLAIN FUNCTION does not support generating the query plans of SQL++ statements within these nested UDFs.
Summary
Couchbase 7.6 introduces new features for UDF debuggability which will help users peek into UDF execution easily.
Reference the following documentation links to learn more, or check out the other Couchbase 7.6 innovations:
